Technical parameter |
||
|
1 |
Decoiler |
1.Bearing: 3T 2.Feeding way: Manual with brake |
|
2 |
Main Forming System
|
1.Roller stations: 13rows 2.Material of Roller: Gcr15#, carburization heat treatment 3.Diameter of main shaft: 50mm 4.Thickness of sheet: ≤3.0mm,Galvanized sheet 5.Material of main shaft: 45# steel 6.Power of main motor: 5.5kw 7.Forming Speed: ≤8-10m/minute 8.Side panel: 14mm 9.Chain: 1 inch |
|
3 |
Cutting device |
1.Material of blade: CR12, heat treatment HRC60-62 2.Cutting device: self length, self counting, automatic stop cutting, control length |
|
4 |
Hydraulic system |
1.Oil pump station:1set 2.Motor power of pump station: 3kw |
|
5 |
Electrical System
|
1.Touch screen brand: Wecon 2.PLC brand: Wecon 3.Automatic length measurement,Automatic quantity measurement 4.Length measurement: Rotary Encoder 5.Power: 380V/50Hz/3PH (According to customer needs) |
|
6 |
Machine Size |
- Size( L×W×H): about 3.8m×0.7m×1.2m |
|
7 |
Weight of the production line |
- Total weight: about 2t |
|
8 |
Process of the production line |
- Decoiler — Forming — Cutting |
